Intel^® H610 Chipset

• • Support Intel^® Core™ 14th/ 13th/ 12th Gen Processors, Intel^® Pentium^® Gold and Celeron^® Processors
  • Processor socket LGA1700
  1. Please go to www.msi.com to get the newest support status as new processors are released.

• 2x DDR4 memory slots, support up to 64GB
• Supports 1R 2133/ 2666/ 3200 MHz (by JEDEC & POR)
• Supports Dual-Channel mode
• Supports non-ECC, un-buffered memory

1. Please refer to www.msi.com for more information on compatible memory.

• 1x HDMI™ 1.4 with HDR port, supporting a maximum resolution of 4K 30Hz
• 1x VGA port, supporting a maximum resolution of 2048×1536 50Hz, 2048×1280 60Hz, 1920×1200 60Hz
  1. Available only on processors featuring integrated graphics.
  2. Graphics specifications may vary depending on the CPU installed.

• 1x PCIe x16 slot (From CPU)
  • Supports up to PCIe 4.0 x16
• 1x PCIe x1 slot (From H610 chipset)
  • Supports PCIe 3.0 x1

• • 1x 4-pin CPU fan connector
  • 2x 4-pin system fan connectors

• 1x Clear CMOS jumper

• 1x 4-pin RGB LED connector
• 4x EZ Debug LED

• 1x 4-pin CPU fan connector
• 2x 4-pin system fan connectors

Realtek^® ALC897 Codec

• 7.1-Channel High Definition Audio

• 1x USB 3.2 Gen 1 5Gbps connector (From H610 chipset)
  • Supports additional 2 USB 3.2 Gen 1 5Gbps ports
• 2x USB 2.0 Type-A connectors (From Hub-GL850G)
  • Supports additional 4 USB 2.0 ports

1. HDMI™
2. VGA
3. Keyboard / Mouse
4. USB 3.2 Gen 1 5Gbps Type-A
5. LAN port
6. Audio connector
7. USB 2.0
